Heavy Duty Self Priming Pump , JET Series Self Priming Sewage Pump For Houshold

Heavy Duty Self Priming Pump, JET Series Self Priming Sewage Pump For Household

Self-Priming Pump Description

JET-L series self-priming pumps are high efficient jet pumps with excellent suction even when there are air bubbles. The pump consists of a single impeller, centrifugal pump, and jet pipe with a nozzle. The series pump is particularly suitable for water supplying in domestic installations, small-scale agriculture watering, and where self-priming operation is demanded.

Pump body: Cast Iron

Impeller: Brass/ Techno-polymer (P.P.O)/ Aluminum

Mechanical Seal: Carbon/Ceramic/Stainless Steel

Nozzle: P.P.O/Aluminum

JET Pipe: P.P.O/Aluminum

Diffuser: P.P.O/Aluminum/Cast Iron

Self-Priming Pump Application

The JET series is composed of a centrifugal pump and a jet pump (injector). The centrifugal pump is generally installed on the ground. The jet pump is installed under the well. The working principle is that the normal pressurized liquid passes through the nozzle to cause low- pressure so that the liquid in the well is sucked into the centrifugal pump. The wellhead is discharged through a centrifugal pump. Because the JET series can pump water from wells 10 meters to 50 meters deep (and any other self-priming pump and clean water pump will not exceed 10 meters) and will not be overloaded, The electric water pump suitable for clean water and non-corrosive liquids, it is widely used in wells in low water areas, factories, domestic water, small irrigation systems, pressurization, flushing, and water transfer.

Self-Priming Pump Data

Self-Priming Pump Construction

Pump

Pump Body: Cast iron/Brass/Stainless steel
Impeller: Brass/P.P.O

Mechanical Seal: Carbon

Diffuser Nozzle: P.P.O

Jetpipe: P.P.O
DIEEUSSOR:P.P.O/Cast Iron

Motor
Single Phase
Heavy-Duty Continuous Work
Motor Housing: Aluminum
Shaft: Carbon Steel / Stainless Steel
Insulation: Class B / Class F
Protection: IP44 / IP54
Cooling: External Ventilation

Self-Priming Pump Precautions

A. Before use, check whether the bolts in the electric pump are loose or not. The cable and plug are intact. The insulation resistance of the motor should be greater than 2 megohms.

B. To prevent electric shock, it is necessary to install corresponding safety measures such as leakage circuit breaker or electric shock protection device and reliably ground

C. The voltage usage range is between 180V and 230V. Otherwise, the service life of the motor will be shortened or burned out. If the electric pump is used far away from the power supply, you should thicken the power transmission line. Otherwise, the voltage will drop, and it will not work.

Self Priming Pump guarantee:

Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except for the damageable spare parts caused by the customer's incorrect manufacturing operation. In addition, after expiration, our company provides cost spare parts for maintenance.

Self Priming Pump Our service:

1). We are happy that the customer gives us some suggestions for price and products.

2). Any questions, please let us know it in the first by E-mail or Telephone. We can deal with them for you in time.

3). Offer our customers the lowest prices. Streamline the buying and paying processes.

4). Deliver goods to our customers all over the world with speed and precision.

5). Ensure the excellent quality of our products.

6). 12 months FREE warranty.

7). Accept OEM


FAQ

1). Q: How about the MOQ?
A: Usually, it is 50 PCS for each model.

2). Q: Are you a factory or a trading company?
A: we make water pumps, motors, alternators, and diesel generators since 2006.

3). Q: Can you accept to use our logo?
A: Yes, we can. Any OEMs are welcome!

4). Q: What are your payment terms?
A: 30% deposit by T/T in advance, pay 70% balance against B/L copy.

5). Q: How about the delivery time?
A: Usually, 10-30days. But it depends on your order quantity.

6). Q: How about the warranty?
A: 1 year from shipped on board date.
