100% Copper Core Electric Automatic Water Pump For Home Water Main 0.5HP 0.37KW
| Place of Origin | China |
|---|---|
| Brand Name | ZOZHI |
| Certification | CE/SGS/ISO |
| Model Number | AUTOQB-60-1 |
| Minimum Order Quantity | 1pc |
| Price | negotiated |
| Packaging Details | Packed in cartons , overall size:280x145x180mm/pc, N.W.: 5.3kgs |
| Delivery Time | 25 working days after received your payment |
| Payment Terms | T/T, L/C |
| Supply Ability | 30000pcs per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Automatic Water Pump | Application | Pumping |
|---|---|---|---|
| Power | 0.5HP / 0.37KW | Flow Max | 35 L/Min |
| Head Max | 35 M | Suction Max | 9 M |
| Switch | Mechanical Pressure Switch | Tank Capacity | 19 L |
| Highlight | irrigation water pumps,pressure booster pump |
||
Product Description
Automatic Water Pump
100% Copper Core Electric Automatic Water Pump For Home Water Main 0.5HP 0.37KW
Features of Domestic Pump
1. Used for 0-60 C clean water
2. A special spray-paint technique, beautiful and more stable
3. 100% copper wire by automatic wiring machine
4. CE TUV RoHS ISO9001 ISO14001 certification
5. A brass plate embedded to avoid impeller jam
Automatic Water Pump Application
- Auto series of a pump is constituted with clean water pump, non-return valve, and air-water separation room, which located on the upside of the pump body.
- During operating, it is no need to use a foot valve, the only thing that you should do is just leave some water in the pump body.
- After a few minutes of running, the water will be sucked out relying on the pump body itself.
- They are particularly suitable for domestic applications such as supplying water from a well, pool, etc.
- It is also suitable for water pressure boosting, gardening, and automatic water supplying if combined with other appliances.
Technical Data
| Model | Output | A | R.P.M. | Q.Max | H.Max | S.Head | Pipe Dia | LxWxH | N.W. |
| HP / KW | 1~220V | (l/min) | (m) | (M) | (mm) | (Kg) | |||
| QB-60 | 0.5 / 0.37 | 1.6 | 2850 | 35 | 35 | 9 | 1"x1" | 280x145x180 | 5.3 |
| QB-70 | 0.75 / 0.55 | 3.6 | 2850 | 45 | 50 | 9 | 1"x1" | 330x180x220 | 9.5 |
| QB-80 | 1 / 0.75 | 4.8 | 2850 | 50 | 55 | 9 | 1½ "x1½" | 330x180x220 | 10 |
| QB-90 | 1.5 / 1.1 | 6.2 | 2850 | 90 | 60 | 9 | 1½ "x1½" | 425x200x220 | 22 |
Other voltages and frequencies available on request
Structural Characteristics
| Main Specification | Standard | Optional |
| Transmission medium | Clean Water | |
| Pump body | Cast Iron | |
| Impeller | Brass | |
| Motor housing | Aluminum | |
| Stator&Rotor | 1. Cold-rolled silicon steel sheet by high-speed punching machine. 2. 100% high-quality copper wire | |
| Front cover | Cast Iron | Brass plate embedded to avoid impeller jam |
| Bearing | Chinese Best Quality Bearing | NSK, SKF, or on request |
| Mechanical seal | Graphene/Ceramic | Silicon Carbon |
| Shaft | Carbon Steel | Stainless Steel |
| Insulation | Class B | Class F |
| Protection | IP44 | IP54 |
| Voltage | 220-240V Single Phase | On Request |
| Frequency | 50HZ | 60HZ |
| thermal protection | No | Yes |
| Automatic Pressure Control System | No | Yes |
| Cooling Type | External Ventilation | |
| Max. Suction lift | 9M | |
| Max. Fluid Temperature | +60℃ | |
| Max. Environment Temperature | +40℃ | |
| Installation | Horizontal | |
| Connect Type | Thread | |
| CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC | ||
Automatic Water Pump
GUARANTEE
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by the customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
OUR SERVICE
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available, feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services from designing, printing to processing. Customers can provide the design according to your request and samples making, also we can advise how to make the products according to customers' target prices.
FAQ
1. Q: What’s the MOQ?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: How can I get the pump?
A: Usually we suggest express for samples, if the volume reaches 1m³, the Seaway will be better.
5. Q: What’s the warranty period?
A: 1 year.
